MULTIFLOW 1/20 LT T1F
MULTIFLOW 1/20 LT T1F
Sale price£1,284.21 GBP
Tab 1
Use this text to share information about your brand with your customers.
Tab 2
Describe a product, share announcements, or welcome customers to your store.
Tab 3
Share information about your shipping rates, return policy or contact information.
GENERAL FEATURES
FEATURES
- Four 0 ÷ 12 VDC pulse outputs with frequency proportional to flowrate
- LED for status indication of each single channel
- Compatible with high conductivity fluids
TECHNICAL FEATURES
BENEFITS
- No mechanical moving parts inside the pipe
- Performances independent from fluid density and viscosity
- Low sensitivity to turbulence
- High precision
- Low maintenance
| Field | Value |
|---|---|
| Code | 4625AA1B1B1 |
| T1 | |
| Flow rate | 1 ÷ 20 l/min |
| MAX Pressure | 20 bar |
| Connection | A-NET |
