EL.PROP.VALVE D.10 T3-T3
EL.PROP.VALVE D.10 T3-T3
Sale price£190.38 GBP
Tab 1
Use this text to share information about your brand with your customers.
Tab 2
Describe a product, share announcements, or welcome customers to your store.
Tab 3
Share information about your shipping rates, return policy or contact information.
GENERAL FEATURES
The Superseal connector of 862 series valves is integrated in the motor body and ensures the watertight integrity of the valve. The indicator LED allows to see the valve status.
- In-line female T3/T3 coupling.
TECHNICAL FEATURES
- Body available with T3 and T3 + EASYFIT fork coupling.
- Available with in-line or 90° couplings.
- Watertight connector integrated in the motor body.
- Valve status LED.
- Breather membrane in PTFE.
- Structure in fiberglass reinforced Nylon®.
- Internal parts in Delrin® and AISI 303 stainless steel.
- Seals in Viton®.
- Internal resettable fuse (disconnect the power supply for 20 seconds to reset).
| Field | Value |
|---|---|
| Code | 862A3110 |
| T3 | |
| On / Off @ 90° | 14 sec. |
| MAX Pressure | 20 bar |
| Use for | |
| @ 1.5bar - 22PSI Flow rate | 60 l/min |
| Absorption @ 12 V | 0.5 A |
| Power supply voltage | 12 Vdc |
